YINGHUA
YINGHUA YH-8180 High Quality Double Sided Copper Clad Laminate
YINGHUA YH-8180 High Quality Double Sided Copper Clad Laminate
FEATURE:
Tg≥170℃ Lead Free Compatible FR-4.0 Double Sided Copper Clad Laminate
Excellent Peel Strength
Ultra Low Z-axis CTE
Excellent Anti-CAF Performance
UV Blocking/ AOI Compatible
Lower Water Absorption
Excellent Dimension Stability
APPLICATIONS:
Consumer Electronics
Power Supplies, Instrumentations
Communications Equipment
Automotives Electronics
Militaries, etc.
YH-8180 SPECIFICATION:
Thickness: 0.05mm to 3.2mm
Tolerance: IPC4101 Class C/M
Copper Foil: 1/4 oz to 6 oz
Standard Size:
940*1245mm(37’’*49’’), 1880*1245mm(74’’*49’’)
1042*1245mm(41’’*49’’), 2082*1245mm(82’’*49’’)
1092*1245mm(43’’*49’’), 2184*1245mm(86’’*49’’)
